ZVM
-Pump
1. Special anti-rust treatment for cast iron pump body and support
2. Anti-block system for impeller
3. Brass impeller
3. AISI 304 shaft
4. Max.liquid temperature: +40℃
5. Max.suction: +9 m
-Motor
1. High efficiency bearing
2. Built-in thermal protector for single phase motor(≤1.5 kW)
3. Insulation class: F
4. Protection class: IPX4
5. Max.ambient temperature: +40℃
| MODEL | POWE | AMPERE | MAX.FLOW L/Min | MAX.HEAD (m) | SUCT.MAX (m) | PIPE | G.W (kg) | Q(m3/h) | 0 | 0.6 | 0.9 | 1.2 | 1.5 | 1.8 | 2.1 | 2.4 | 3.0 | 3.6 | |
| Kw | Hp | Q(L/min) | 0 | 10 | 15 | 20 | 25 | 30 | 35 | 40 | 50 | 60 | |||||||
| ZVM 300 | 0.3 | 0.4 | 2.5 | 30 | 30 | 9 | 1″×1″ | 5 | H (m) | 30 | 20 | 15 | 12 | 8 | 5 | - | - | - | - |
| ZVM 370 | 0.37 | 0.5 | 3 | 35 | 40 | 9 | 1″×1″ | 5.3 | 40 | 30 | 25 | 20 | 15 | 10 | 5 | - | - | - | |
| ZVM 600 | 0.6 | 0.9 | 4.5 | 50 | 55 | 9 | 1″×1″ | 8.8 | 55 | 50 | 40 | 35 | 30 | 25 | 20 | 10 | 5 | - | |
| ZVM 750 | 0.75 | 1.0 | 5.2 | 55 | 65 | 9 | 1″×1″ | 10 | 65 | 60 | 50 | 45 | 35 | 28 | 22 | 15 | 5 | - | |
| ZVM 800 | 0.75 | 1.0 | 5.2 | 40 | 70 | 9 | 1.5″×1.5″ | 10 | 70 | 60 | 50 | 35 | 25 | 15 | 5 | - | - | - | |
| ZVM 1100 | 1.1 | 1.5 | 7 | 65 | 75 | 9 | 1″×1″ | 15.5 | 75 | 70 | 65 | 60 | 55 | 50 | 45 | 40 | 30 | 18 | |
| ZVM 1500 | 1.5 | 2.0 | 8 | 75 | 80 | 9 | 1″×1″ | 16 | 80 | 75 | 70 | 65 | 60 | 55 | 50 | 45 | 40 | 30 | |
| ZVM 2200 | 2.2 | 3.0 | 9.2 | 90 | 90 | 9 | 1″×1″ | 22 | 90 | 85 | 80 | 75 | 70 | 65 | 60 | 55 | 50 | 40 | |
| N0. | Description | N0. | Description | N0. | Description |
| 1 | Bearing | 18 | Screw | 35 | |
| 2 | Rotor | 19 | Terminal board | 36 | |
| 3 | Stator | 20 | Capacitor holder | 37 | |
| 4 | Motor case | 21 | Motor front bracket | 38 | |
| 5 | Waterproof fairlead | 22 | Splash guard | 39 | |
| 6 | Motor end cover | 23 | O-ring | 40 | |
| 7 | Fan | 24 | Mechanical seal | 41 | |
| 8 | Fan cover | 25 | Circlip | 42 | |
| 9 | Screw | 26 | Key | 43 | |
| 10 | Motor tie-rod | 27 | Impeller | 44 | |
| 11 | Adjusting ring | 28 | Dust cap | 45 | |
| 12 | Cable sheath | 29 | Airscrew | 46 | |
| 13 | Screw | 30 | O-ring | 47 | |
| 14 | Capacitor | 31 | Pump body | 48 | |
| 15 | Terminal box | 32 | Washer | 49 | |
| 16 | Screw | 33 | Screw | 50 | |
| 17 | Handle sheath | 34 | 51 |
